Physical Dimensions: 21.5 x 17 x 6 cm
Weight: ~1.2kg
Enclosure: Powder-coated 1.6mm galvanized steel
Audio Outputs:
- 6 balanced mono, line-level 1/4" outputs (8.4dBu / 2.04Vrms)
- Stereo headphone output (3.5mm jack, 10dBu / 2.5Vrms per channel, unloaded)
Audio Input:
- Balanced mono aux input (3.5mm jack, 8.7dBu / 2.1Vrms single-ended or 15.3dBu balanced)
- Hard clip overvoltage protection at 9dBu (2.2Vrms) single-ended / 18dBu (4.4Vrms) differential
MIDI:
- MIDI In & Out (5-pin DIN)
- Supports Type 0 MIDI file playback (including CC and PC messages)
- Outputs MIDI clock
USB:
- USB-B for computer connection and file transfer
- USB-A (reserved for future functionality)
Storage:
- Removable SD card (FAT32)
Playback:
- Simultaneous playback of up to 6 stereo or mono 16-bit, 44.1kHz WAV files
Display: 128 x 64 pixel LCD
Power Supply:
- Included: 12V DC 1000mA, center-positive, with switchable blades (110-240V input)
Operation:
- Controllable via hands, feet, or MIDI controller
